Vacuum EPS Machine
Mould cavty Sze:2080×(1240-800)×630 mm
Bock SzR:2000×(1200-800)×600 mm
Capacity@15kglm²:4 mhkcyde
Cornocted LoadPowar:20735 KW
Overall Dimenslon(LxW×H0):5700×400×3300 mm
Wigft:8000 KG
Hangzhou Fuyang Dongshan Plastic Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of vacuum eps machine in China, also supports customized service with low price. Welcome to wholesale high quality vacuum eps machine for sale here from our factory. Contact us for pricelist.
Advanced Vacuum EPS Block Molding Machine Ensuring Dry and Stable Blocks for Cutting
Engineered with modern vacuum molding technology, the Advanced Vacuum EPS Block Molding Machine provides an efficient and reliable solution for manufacturers who require stable EPS blocks for precise cutting into insulation boards and panels. In the eps factory, it can used to produce high-quality EPS blocks with excellent dryness, dimensional stability, and structural consistency.
Key Features
Advanced Vacuum System
High-efficiency vacuum cooling rapidly removes heat and moisture, resulting in low-moisture, well-stabilized EPS blocks that are ideal for immediate cutting.
Excellent Block Dryness
Reduced internal moisture shortens curing time and minimizes shrinkage or deformation, ensuring consistent block quality.
Uniform Density Distribution
Precise control of steam pressure and temperature ensures even fusion and consistent density throughout the block.
4. Stable and Accurate Dimensions
Optimized molding and cooling processes improve dimensional accuracy, reducing cutting waste and enhancing yield.
5. Energy-Efficient Operation
Optimized steam and vacuum systems lower energy consumption while maintaining high production efficiency.
6. Automated Control System
PLC-based automation with a user-friendly interface allows real-time monitoring, parameter adjustment, and fault detection.
7. Robust Machine Structure
Heavy-duty frame and high-quality components ensure stable operation under continuous industrial production conditions.
Features
- Stress-Relieving & Non-Deforming Frame
- High-Strength Structure
- Superior Anti-Corrosion Protection
- Multi-Level Safety System
- 20% Steam Savings
- Fully Automatic PLC Control
Advantages
The company conducted a competitive advantage analysis to identify its strengths and weaknesses compared to its rivals.
Efficient Production
It has a high production efficiency and can produce a large quantity of EPS foam sheets in a short time to meet the large-scale market demand.
01
Stable Quality
The advanced production process and precise control system ensure the stable quality of the sheets. The cell structure is uniform and fine, and performance indicators such as the density and strength of the sheets meet high standards.
02
Energy Saving and Consumption Reduction
The adoption of energy-saving heating and foaming technologies effectively reduces energy consumption and production costs, and also conforms to the development trend of environmental protection and energy conservation.
03
High Flexibility
According to different customer needs, the production parameters can be adjusted to produce EPS foam sheets of different thicknesses, densities, and specifications to adapt to diverse application scenarios.
04
Easy Operation
The operation interface of the equipment is user-friendly, making it easy for workers to operate and maintain. It reduces the technical requirements for operators and improves the convenience of production.
05
Technical Specifications
| Item | Unit | DSHA2000 | DSHA3000 | DSHA4000 | DSHA6000 | DSHA8000 | |
| Mould cavty Sze | mm | 2080×(1240-800)×630 | 3080×(1240-800)×630 | 4100×(1240-800)×630 | 6120×(1240-800)×630 | 8140×1240×630 | |
| Bock SzR | mm | 2000×(1200-800)×600 | 3000×(1200-800)×600 | 4000×(1200-800)×600 | 6000×(1200-800)×600 | 8000×1200×600 | |
| Steam | Entry | hch/mm) | 5*(DN125) | 5"(DN125) | 6"(DN1500 | 8"(DN2000 | 8"(DN200) |
| Consumphion | kg(cyche | 25-45 | 45-65 | 60-85 | 95-120 | 115-160 | |
| Prassure | Mpa | 0.6-0.8 | 0.6-0.8 | 0.5-0.8 | 0.6-0.8 | 0.5-0.8 | |
| Copressed Air | Entry | hch/mm) | 1.5*(DN40 | 1.5"(DN40 | 2"(DNS0) | 25"(DN65) | 3"(DN80) |
| Corsumphion | miyce | 1.5-2 | 1.5-2.5 | 1.8-2.5 | 2-3 | 2.5-3 | |
| Pressure | Mpa | 0.6-0.8 | 0.5-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | |
| VacumCoolng Water |
Entry | hch/mm | 1.5*DN40) | 1.5"(DN40 | 1.5"(DN40) | 1.5"(DN40) | 1.5"(DN40) |
| Corsumchion | mioycke | 0.4 | 0.6 | 0.8 | 1 | 2 | |
| Prassure | Mpa | 0.2-0.4 | 02-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | |
| Dralnage | VacumVert | hch/mm | 4*(DN100) | 5"(DN125) | 5"(DN125) | 5"(DN125) | 5"(DN125 |
| Sheam Vent | hch/mm) | 4*(DN100) | 6"(DN150) | 6"(DN1500 | 6"(DN150) | 8"(DN200) | |
| AIr Coolng Vent | hch(mm) | 4*(DN100) | 5"(DN125) | 6"(DN150 | 8"(DN200) | 8"(DN200 | |
| Capacity@15kglm² | mhkcyde | 4 | 6 | 7 | 8 | 8 | |
| Cornocted LoadPowar | KW | 20735 | 2035 | 2540 | 2951 | 3155 | |
| Overall Dimenslon(LxW×H0 | mm | 5700×400×3300 | 7200×4000×3500 | 11000×4500×3500 | 12600×4500×3500 | 15700*4600×3500 | |
| Wigft | KG | 8000 | 9500 | 12000 | 14000 | 18000 | |
Product Applications
Building Insulation Field
Packaging Industry
Advertising and Decoration Industry
Cold Chain Logistics Field
Other Fields
Why Choose Us
Certifications and Awards
the final view of project
Exhibitions with Global Customers
Our Service
Dongshan EPS Machine ServicesProfessional Pre-Sales, In-Sales & After-Sales Support for Global EPS Manufacturers
Pre-Sales
Technical Consultation
Customized Solutions
Quotation & Project Planning
In-Sales
Factory Tour
Installation Guidance
Operation Training
After-Sales
Technical Support
Spare Parts Supply
Overseas Service
Turnkey EPS Production Line layout design service:
Package and shipment
