2D Foam Cutting Machine

Empower your business with our Easy Operation Automatic EPS Cutter. Specially built for small to medium polystyrene enterprises, this 2D foam cutting machine delivers professional-grade precision, automated efficiency, and a simplified workflow to maximize your workshop's productivity.

Send Inquiry

Hangzhou Fuyang Dongshan Plastic Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 2d foam cutting machine in China, also supports customized service with low price. Welcome to wholesale high quality 2d foam cutting machine for sale here from our factory. Contact us for pricelist.

Easy Operation Automatic EPS Cutter 2D Foam Cutting Machine for Small to Medium Polystyrene Enterprises

Core Technical Highlights

Simplified "One-Touch" Automation

Designed for rapid deployment, the machine features an intuitive control system that automates the cutting sequence. Operators can set dimensions and speeds quickly, reducing the learning curve and minimizing human error during production.

Precision 2D Motion Control

Utilizing high-quality stepper motors and synchronized timing belts, the machine ensures smooth, linear movement across the X and Y axes. This delivers clean, square edges on EPS blocks and sheets, essential for construction and packaging standards.

Adjustable Hot-Wire Array

The cutting frame supports multiple horizontal and vertical wires that can be manually adjusted to various intervals. This allows the machine to slice a single large EPS block into dozens of thin sheets in a single pass, significantly boosting productivity for SME-scale orders.

Intelligent Thermal Regulation

Equipped with a digital voltage regulator, the machine maintains a constant wire temperature. This prevents "over-melt" at slow speeds and ensures a clean, burr-free surface finish, which reduces the need for secondary sanding or trimming.

Compact & Rigid Frame Design

The machine is built with a reinforced, vibration-dampening aluminum or steel alloy frame. Its compact footprint is specifically engineered for facilities with limited floor space, providing industrial stability without the bulk of a large-scale continuous line.

System Component Breakdown

Station	Function	Advantage
Horizontal Cutter	Slices the block into the desired thickness.	Multi-wire frames for up to 30+ slices at once.
Vertical/Side Cutter	Trims the edges and sets the width.	Ensures perfectly square edges for interlocking.
Cross-Cutter	Cuts the long strips into specific lengths.	High-speed oscillation for "burr-free" finishes.
Auto-Stacker	Automatically stacks finished panels.	Reduces labor and prevents panel damage.

Overview

The automatic wire - setting foam plate cutting machine adds horizontal auto - wire - setting, set - length cross - cutting, and auto - operation on the regular sheet cutter. It solves manual wire - hanging hassle, inaccuracy, and large cross - cut length tolerance, boosting cutting accuracy and output. Ideal for small - medium foam sheet orders, it's the top choice for EPS sheet factories.

product-696-331

Mechanical Characteristics

1. Horizontal, vertical and cross - cut voltages are controlled by three separate transformer - regulator pairs.

2. PLC and HMI control the machine THorizontal wires can be set to automat ic. Set panel thickness, and three different thicknesses are set automatically. Set three cross - cut lengths for a single block, and the machine cuts accordingly. In automatic mode, press start, the machine cuts horizontally and vertically first, then cross - cuts automatically. Operation ends when the block is removed.

3. An alignment device for block place ment ensures accurate block - cutting.

4. Electrical limit and mechanical protec tion safeguard the machine's safe operation.

Advantages

FC200/250 series CNC foam cutter suit for 2D profile cutting with multi cutting wire, which have big capacity and high accuracy, this machine is specially for exterior cornice moulding, facade cladding and deco elements.

The automatic wire - setting foam plate cutting machine adds horizontal auto - wire - setting, set -length cross - cutting, and auto - operation on the regular sheet cutter. It solves manual wire – hanging hassle, inaccuracy, and large cross - cut length tolerance, boosting cutting accuracy and output. Ideal for small - medium foam sheet orders, it's the top choice for EPS sheet factories.

This is a continuous, fully - automatic PLC - controlled foam plate cutting machine. It moves the plate while fixing the cutting frame, enabling three - direction horizontal, rigid, cut - off, and continuous cutting of foam plates. With numerous cutting wires and high cutting speed, the manipulator - adjusted wires automatically in 1 - 3 minutes, 10 times faster than manual adjustment. It features high precision and automation, making it essential for medium - to - large foam plate plants.

Technical Specifications

Item	Unit	DSFC SAXIS
Max Cutting Size	mm	2000~6000X1300X1300
Min.Cutting Thickness	mm	15
Cutting Speed	m/min	0.4~1
Max.Wires In Horizontal	piecs	32
Max.Wires In Cross Vertical	piecs	10
Wires In Cross Cutting	piecs	1
Hot Wire Specification	mm	0.4
Connected Load	kw	21
PowerSupply	VHZ	380/50
Weight	kg	1800
Contour Size	M.M	4500×8500×1864×2850
Step Motor For Wire-setting(2unit)	N.M	2-8.5 (Close loop)
Step Motor For Cross CutingMovement	N.M	12(Close loop)
StepMotor Cross Cutting	N.M	35 closeloop(up&down)
Horizontal Shelf Motor	kw	0.75 By frequency converter
